bs 1387 carbon steel pipe, ms round pipe weight chart
- group name
- Erw Steel Pipe
- Min Order
- 15 ton
- brand name
- Youfa Steel Pipe Manufacturer
- Nearest port for product export
- Tianjin Port, Shanghai Port,etc.
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW
- Acceptable payment methods
- T/T, L/C, D/P D/A
- update time
- Wed, 25 Dec 2024 02:33:06 GMT
Paramtents
Pipe Ends plain, grooved,bevelled, threaded
Surface Treatment Black,Oiling,Painted,galvanized
Length 5800/6000mm or as requirement
Outer Diameter 19-355mm
Material Q195 Q235 Q345
Packging & Delivery
-
Min Order15 ton
Briefing
bs1387 carbon steel pipe, ms round pipe weight chart
Detailed
BS1387 Carbon Steel Pipe Characteristic
BS1387 is a British standard specification for steel pipes used for conveying gas, water, and oil.
BS1387 Circular Pipe Specification:
Outside Diameter: DN 15mm to 150mm; Thickness: Light, Medium, Heavy; Length: usually 6m, customized other length
ERW Steel Pipe Ends:
Threaded Ends: BS1387 steel pipes typically have BSP threaded ends to facilitate easy installation and connection with fittings; Plain Ends; Beveled Ends.
Steel Tubes Surface Coating:
Hot-Dipped Galvanization: The standard often requires the pipes to be hot-dipped galvanized to provide corrosion resistance, especially for outdoor and underground applications; Natural Black; Color Painted;
BS1387 Ms steel round Pipes Weight Chart
Nominal Size | Ligtht Black Tubes Plain End | Medium Black Tubes Plain End | Heavy Black Tubes Plain End | |||
DN | Wall Thickness | Weight kg per meter | Wall Thickness | Weight kg per meter | Wall Thickness | Weight kg per meter |
15 | 2.0mm | 0.947 | 2.6 | 1.21 | 3.2 | 1.44 |
20 | 2.3mm | 1.38 | 2.6 | 1.56 | 3.2 | 1.87 |
25 | 2.6mm | 1.98 | 3.2 | 2.41 | 4.0 | 2.94 |
32 | 2.6mm | 2.54 | 3.2 | 3.10 | 4.0 | 3.80 |
40 | 2.9mm | 3.23 | 3.2 | 3.57 | 4.0 | 4.38 |
50 | 2.9mm | 4.08 | 3.6 | 5.03 | 4.5 | 6.19 |
65 | 3.2mm | 5.71 | 3.6 | 6.43 | 4.5 | 7.93 |
80 | 3.2mm | 6.72 | 4.0 | 8.37 | 5.0 | 10.3 |
100 | 3.6mm | 9.75 | 4.5 | 12.2 | 5.4 | 14.5 |
125 | - | - | 5.0 | 16.6 | 5.4 | 17.9 |
150 | - | - | 5.0 | 19.7 | 5.4 | 21.3 |
BS1387 Pipes Application
Coated Bs1387 Carbon Steel Pipes
commonly used for water supply, gas, and oil conveyance.
also used for general engineering and structural purposes.
