bs1387 class A B C galvanized steel pipe/ GI PIPE LIST
- group name
- Galvanized Steel Pipe
- Min Order
- 25 ton
- brand name
- Youfa Steel Pipe Manufacturer
- Nearest port for product export
- Tianjin Port, Shanghai Port,etc.
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW
- Acceptable payment methods
- T/T, L/C, D/P D/A
- update time
- Tue, 04 Nov 2025 10:28:29 GMT
Paramtents
Type Galvanized
Material Q195/Q235/Q355
Surface finish Powder Coating
Delivery time Within 35 Days
Shape Round Shape
Packging & Delivery
-
Min Order25 ton
Briefing
bs 1387 class A B C galvanized steel pipe/ GI PIPE LIST
Detailed
BS1387 Carbon Steel GI Pipe Detail Information
BS1387 is a British Standard Specification for screwed and socketed steel tubes and tubulars and for plain end steel tubes.
|
Size/Diameter
|
1/2"-8" (21.3-219mm)
|
|
|
Wall thickness (W.T.)
|
1.8-5.5mm
|
|
Length | 6.0M, 6.5M, 5.8M, 4.5M,1m-12m ,by customer's requirements | |
Certificates international standard | ISO 9000-2001,CE EN10219 certificate, BV certificate | |
Similar Chinese Standards | GB/T13793, GB/T3091-2001 | |
Materials | S195, S235GT, S355, Q345/Q235/Q195 | |
|
Technique
|
Welded
|
|
|
Packing
|
1. Packed by steel strips
2. Woven cloth with 7 slats
3. According to PI |
|
Shipment | 1) Container: 26 tons per container for thick wall thickness pipe.
20"container: the max pipe length 5.85 m without coupling, 5.8 m with coupling;
40"container: the max pipe length 11.8 m or 5.97 m in two rows.
2) Bulk carrier: no limits on pipe length. | |
Country of origin | China | |
Remark | 1. Payment terms : T/T, L/C
2. Terms of trade : FOB, CFR, CIF 3. Minimum order : 2 tons per size 4. Lead time : on or before 30 days . | |
Gi Pipe Class A B C Thickness Chart
Class A light tubes are marked with brown.
Class B medium tubes are marked with blue.
Class C heavy tubes are marked with red.
|
Out diameter
|
Light Steel Tube Wall Thickness
|
Medium Steel Tube Wall Thickness |
Heavy Steel Tube Wall Thickness
|
|
inch
|
mm
|
mm |
mm
|
|
1/2"
|
2.0
|
2.6 | 3.2 |
3/4" | 2.3 | 2.6 | 3.2 |
1" | 2.6 | 3.2 | 4.0 |
1-1/4" | 2.6 | 3.2 | 4.0 |
1-1/2" | 2.9 | 3.2 | 4.0 |
2" | 2.9 | 3.6 | 4.5 |
2-1/2" | 3.2 | 3.6 | 4.5 |
3" | 3.2 | 4.0 | 5.0 |
4" | 3.6 | 4.5 | 5.4 |
5" | - | 5.0 | 5.4 |
6" | - | 5.0 | 5.4 |
Pls don't hesitate to contact us if you need other sizes. | |||
Customized Process Type for Galvanized Steel Pipe
1. Stamping / Embossing
The cost of embossing is expensive than stamping. We usually choose stamping on the outside body of pipe.
2. Threaded ends / Socketed & plastic cap protection
BSP threaded and NPT threaded with coupling separately on one end and cap on the other end.
3. Grooved ends
Grooved ends gi pipes are connected by coupling. If you need coupling we can supply separately.
4. Bending / Arched
Bending gi pipes are usually used in greenhouse structure.
5. Water proof bag / Plastic bag protection
Only pipe ends pvc packaged or all packed.
Galvanized Steel Pipe Test and Quality Control
YOUFA Galvanized steel pipes cover one-third of the Chinese market
How does Youfa guarantee galvanized pipe quality ?
1. Youfa factories source their raw materials for manufacturing steel pipes from well-established and reputable Chinese enterprises such as HBIS, Shougang, Baotou Steel, Xintiangang, Jinxi Steel, and others.
2. Youfa Group has 4 labs with CNAS certificates in our own factories. We promise that before the goods leave the factory, there will be professional quality inspection personnels to conduct on-site inspections of materials, specifications, etc., and take pictures and archive them.
3. During the cargo transportation process, we take photos to record the loading status of the goods.
4. Youfa hot galvanized steel pipes are certified by CE, UL, ISO 9001, ISO 14001.
Youfa Brand Steel Pipe Production Range Details
|
Main Products
|
Size
|
Wall Thickness
|
Production Lines
|
Producing Capacity |
|
ERW steel pipe
|
1/2" -- 8"
|
1.5mm--10.0mm
|
13
|
1,000,000 tons per yesr |
|
Hot-dipped galvanized steel pipe
|
1/2" -- 8"
|
1.5mm--10.0mm
|
18
|
1,500,000 tons per year |
Square Rectangular steel pipe | 20x20--400x400mm,
20x40--400x600mm | 1.3mm--20mm | 10 | 800,000 tons per year |
Hot-dip galvanized
square / rectangular steel pipe | 20x20--200x200mm,
20x40--250x150mm | 1.5mm--7.5mm | 3 | 250,000 tons per year |
|
Oil casing pipe, SSAW steel pipe
|
219mm-2020mm
|
5.0mm--28mm
|
5
|
1,50,000 tons per year |
Steel-plastic complex
steel pipe | 1/2"--12" | 1.5mm--10.0mm | 9 | 100,000 tons per year |
